A huge and innovative tank

The Avata cartridge by Aspire can hold up to 15 ml of e-liquid. Even your little 10 ml bottle doesn’t stand a chance. Once filled, you’re set for quite a while: no more constant refilling.

Large-capacity tanks often have a tendency to leak… but not this one. Aspire came up with a clever solution to keep your fingers clean. This cartridge is divided into two clearly separated sections:

• 5 ml of e-liquid in direct contact with the coil, ready to vape;
• 10 ml kept in reserve, patiently waiting its turn to become vapour.

To transfer the reserve into the main tank, it couldn’t be simpler: a small valve located underneath the cartridge allows the e-liquid to flow from one chamber to the other. Once the transfer is done, simply close the valve with a quick thumb press. Initial filling is also done from the bottom.

An integrated coil that delivers delicious vapour

The Avata cartridge features a built-in, non-replaceable coil. When it reaches the end of its life, there’s no fiddly disassembly involved: simply replace the entire cartridge.

You have two options to choose from: a 0.4 ohm version for a rich RDL vape, and a 0.6 ohm version offering a slightly tighter draw.

Avata 0.4 ohm: RDL – 20 to 30 W (automatic adjustment) – PG/VG ratios from 50/50 to 40/60 – recommended nicotine strengths up to 12 mg/ml.

Avata 0.6 ohm: Loose MTL – 14 to 19 W (automatic adjustment) – PG/VG ratios from 60/40 to 50/50 – recommended nicotine strengths up to 20 mg/ml.

Using the Avata cartridge

Filling the tank

• Remove the cartridge from the Avata battery.
• Open the valve to fill both the main tank and the reserve.
• Lift the silicone tab.
• Fill generously with e-liquid (there’s plenty of space, take advantage of it!).
• Close the silicone tab and the valve.
• Reinsert the cartridge into the pod.

Replacing the cartridge

• Remove the cartridge with the worn coil.
• Insert a new Avata cartridge.
• Important: if the coil is brand new, allow it to soak for 10 minutes before vaping. Make sure the main tank (the lower one) contains e-liquid. If flavour drops or a burnt taste appears, it’s time to replace the cartridge.
